Boring shank

1. Mature technology, advanced production equipment and strict product testing. We are picky about every detail of Boring shank.
2. ZE series boring shank is not easy to deform when it is used for a long time to ensure stable accuracy.
3. exquisite craftsmanship, each ZE series boring shank is carefully selected raw materials through cutting, rough turning, heat treatment, Carburizing, fine grinding, quality inspection and other processes.

Information
Download

Introduction to ZE series boring shank:

All the boring tool shanks of ZE series boring shank adopt modular interface design, and the end face is designed with special angle, so that the boring tool head can be closely connected with the original sports of the tool handle during assembly, thus achieving high rigidity.

Advantages of ZE series boring shank:

After high hardness treatment, ZE series boring shank is not easy to deform and ensures precision.
The exquisite workmanship of ZE series boring shank is made from imported machine tools.
The body of ZE series boring shank is made of high quality steel with good rigidity.
Boring head shank is suitable for use in all kinds of cutting center machine tools, with tool handles and pull nails, fast and efficient.

ZE series boring shank

Specification parameters of ZE series boring shank:

Order No.	D1	D2	M	L	L1	L2	L3	Weight
BT30-ZE23-60	23	——	73	60	100	73	——	0.5
BT30-ZE29-100	29		118	100	145	118		0.8
BT30-ZE37-100	37		108	100	155	108		1.0
BT30-ZE48-100	48		113	100	160	113		1.2
BT40-ZE23-60	23		68	60	100	68		1.1
BT40-ZE23-80			88	80	120	88		1.2
BT40-ZE23-100		36	100	100	140	108	60	1.2
BT40-ZE29-80	29	——	93	80	125	93	——	1.2
BT40-ZE29-100			113	100	145	113		1.3
BT40-ZE29-125		40	121	125	170	138	76	1.5
BT40-ZE37-100	37	——	123	100	155	123	——	1.5
BT40-ZE37-125	37		148	125	180	148		1.7
BT40-ZE48-100	48		128	100	160	128		1.8
BT40-ZE48-125	48		153	125	185	153		2.1
BT40-ZE60-100	60		143	100	175	143		2.1
BT40-ZE60-125	60		168	125	200	168		2.8
BT40-ZE80-100	80		158	100	190	158		2.9
BT50-ZE23-100	23		97	100	140	97		3.8
BT50-ZE29-100	29		102	100	145	102		3.9
BT50-ZE29-125	29		127	125	170	127		4.0
BT50-ZE37-100	37		112	100	155	112		4.0
BT50-ZE37-125			137	125	180	137		4.2
BT50-ZE37-150			162	150	205	162		4.5
BT50-ZE48-100	48		117	100	160	117		4.2
BT50-ZE48-150			167	150	210	167		5.1
BT50-ZE48-200			217	200	260	217		5.4
BT50-ZE60-150	60		182	150	225	182		5.2
BT50-ZE60-200			232	200	275	232		6.5
BT50-ZE60-250			282	250	325	282		7.3
BT50-ZE80-150	80		197	150	240	197		7.1
BT50-ZE80-200			247	200	290	247		8.5
BT50-ZE80-250			297	250	340	297		9.9

boring shank with draw bar

The above models do not include boring heads and pull studs, please order them separately if necessary.
